The XP652 is a full feature introductory computer
radio that can be used for airplanes and/or
helicopters. This manual is divided into two main
sections — the first for airplanes and the second for
helicopters. You need only refer to the section that
pertains to the type of model you are programming —
e.g., if you are programming your XF652 for helicopters,
follow the instructions in the helicopter section.
Blank data sheets are included at the end of both
sections. Once you have input all the necessary data
into your transmitter for a particular model, we
strongly recommend that you immediately write that
information down on a copy of the data sheet provided.
This is to insure that, in the rare case of a memory
failure, you will not lose your data.
Airplane and Helicopter Mode
•
Easy-to-read LCD screen
•
Five model name entry
•
Five model memory
•
Dual rates on aileron and elevator
•
Dual rates can be combined on one switch
•
Exponential rate on aileron and elevator
•
Trainer system compatible with most other JR
radios
•
Flush mounted programming buttons
•
Computer designed ergonomically styled case
•
Adjustable stick length
•
Throttle trim only affects idle position
•
Two speed scrolling—Press and hold the
appropriate button to scroll quickly or press and
release to scroll in steps.
•
FM/PCM selectable
•
Fail-safe/fail-safe memory (PCM only)
•
Trim offset memory
Airplane Mode
•
Aileron to rudder mixing
•
Elevator to flap mixing
•
Flap to elevator mixing
•
Flaperons mixing
•
Delta wing mixing
•
Aileron differential
•
V-tail mixing
•
Three programmable mixes
•
Mixing differential
Helicopter Mode
•
Two 3-point throttle curves
•
Two 3-point pitch curves (three when throttle
hold is activated)
•
Flight mode switch can combine throttle curve,
pitch curve, dual rates, and gyro sensitivity
•
Throttle hold with rudder offset
•
Revolution mixing up and down
•
Programmable mixing
•
Stunt Trim
•
Optional CCPM Swashplate mixing
R600 Receiver
•
The R600’s extremely compact size allows it to fit
easily in limited-space airplanes and helicopters.
It’s ultra-low weight keeps overall model weight
down.
•
An independent laboratory ranked the R600
receiver with JR’s patented ABC&W circuitry as
one of the best receivers ever tested in terms of
3IM, 2IM, adjacent channel rejection, signal-to-
noise ratio, and on-channel capture point.
•
A special “unwanted interference limiter” ignores
signals outside of the R600’s band width when
the receiver is on and the transmitter is off. The
limiter also prevents servos from random
glitching when other transmitters are operating
in close proximity.
•
The electrical circuitry in the R600 is state-of-the-
art surface mount technology (SMT). These SMT
components draw less current, thus increasing
flying time. Flush mounting of these components
also reduces the risk of vibration wear and
damage.
•
The R600 is compatible with all JR FM-
transmitting radios.
9
XP652 MANUAL Introduction
CHAPTER 1:USING THIS MANUAL
•
Introduction
USING THIS MANUAL
1
CHAPTER 2:FEATURES
•
Introduction
TRANSMITTER FEATURES
2.1
RECEIVER FEATURES
2.2
