JR XP652 User Manual

81
XP652 MANUAL Helicopter
CHAPTER 7:FUNCTIONS
•
Helicopter (Function Mode)
continued
1. Press the Channel button once until MIX ASW
appears.
2. Press the + or - button to select the desired switch
to be used to activate the mixing, or leave as ON if
a constant mix is desired.
(Refer to Chart A on the preceding page for possible
mix/switch selections.)
1. Press the CHANNEL button twice until MIX A CH
appears on the screen.
2. Press the + button to select the desired “ Master
Channel” (1-6).
3. Press the - button to select the desired “slave
channel” (1-6). Refer to Chart B on the preceding page
for channel number clarification.
PROGRAMMABLE MIXING (A)
•
Function Mode (continued)
7.11
MODE
ENTER
CHANNEL
32
ACH
Press the CHANNEL button
until MIX A CH appears.
Press to select
“Master”
channel desired.
Press to select “Slave”
channel desired.
MASTER
CHANNEL
SLAVE
CHANNEL
INCREASE
CLEAR
MIX
+–
DECREASE
Assigning Channels
MODE
ENTER
CHANNEL
O N
A5W
Press the CHANNEL button
until MIX ASW appears.
Press the + or - buttons to select
the desired switch to be activated
(refer to Chart A on preceding page)
SWITCH
CHOICES
ON
F1
FO
H
INCREASE
CLEAR
MIX
+–
DECREASE
Switch Selection
