JRC JHS-800S - Block Diagram

Equipment Overview
1-16
1.5 Block diagram
WKR ANT TRX ANT
JHS-800S
Marine VHF
Radiotelephone
NQEｰ1845/184 6/184 7B
Handset Connection Box
NQA-2443
Sensor LAN switch
（HUB）
Emergency
light
NBD-965
AC/DC Power supply
GPS ※
VDR (AF)
MFD
DMC
RMS (VDR)
BAM ※※
Central DIM ※※
RP-D10 Prin ter
CFS-810
DPYC-2.5
CFS-820
DPYCS-2.5
DPYCS-4
AC100V ~ AC240V
DC24V
TTYCSLA-1
TTYCSLA-1T
TTYCSLA-1
LAN
LAN
LAN
LAN
LAN
LAN
LAN
CFS-840
NVS-423R/823R
External speaker
NQEｰ184 5/184 6/184 7B
Handset Connection Box
MPYCSLA-4
MPYCSLAｰ7
MPYCSLA-7
BTR-155
Wireless
Speaker Mic
CFS-830
N-P-10U
RG-10UY
N-P-10U
7ABJD000 4
Antenna
N-P-10U
N-P-10U
7ABJD000 4
Antenna
CFS-830
CFS-830
TTYCSLA-1
CQD-10
Connection Box
NCM-980
Controller
No.1
NCM-980
Controller
No.2
AIS ※
Note)
※ Connection via LAN is also available.
※※ Connection using TTYCSLA-1 is also available.
(Only one system among AIS, BAM or Central DIM is selectable.)
BTR-155
Wireless
Speaker Mic
NQW-980
Handset
BTR-155
Wireless
Speaker Mic
NQW-980
Handset
CQD-10
Connection Box
CQD-10
Connection Box
NQW-980
Handset
CQD-10
Connection Box
CQD-10
Connection Box
DPYC-2.5
TTYCSLA-1
CFS-830
NCM-980
Controller
No.3
BTR-155
Wireless
Speake r Mic
NQW-980
Handset
CQD-10
Connection Box
TTYCSLA-1
CFS-830
NCM-980
Controller
No.4
BTR-155
Wireless
Speake r Mic
NQW-980
Handset
CQD-10
Connection Box
TTYCSLA-1
RG-10UY
DPYC-2.5
DPYC-2.5
DPYC-2.5
DC12V ~ DC48V
