4-33
[V] Fix mode setting (Fix mode)
Procedures 1. Press [RADAR MENU] key.
The Main Menu will appear.
2. Press [7] key.
The NAV Equipment Setting screen will appear.
3. Press [7] key.
The GPS Setting screen will appear.
4. Press [1] key.
The GPS Process Setting screen will appear.
5. Press [5] key.
From the pull-down menu, the following modes can
be selected:
2D: Two-dimensional position fixing mode. Height cannot be acquired.
3D: Three-dimensional position fixing mode. Height can be acquired.
AUTO: Either two-dimensional or three-dimensional optimum position fixing mode can
be automatically selected.
6. After the entry has been completed, press [9] key to send the settings to
the GPS receiver.
