3.16 CONNECTING TO AIS (NQA-2103)
(OPTION)
1) Install the AIS process circuit
If AIS process circuit is not installed in the radar process unit, install it accordi
n
g to the procedures below:
(1) Remove the radar process unit back cover.
(2) Remove the radar process unit cabinet cover, loosen the screws that mount the terminal board to the
cabinet, an
d remove the terminal board from the radar process unit cabinet.
3-29
