3.14 TARGET TRACKING
(NCA-877WA/877A) (OPTION)
Install the target tracking unit in the
ra
dar process unit according to the procedures below:
(1) Remove the radar process unit cabinet cover, loosen the screws that mount the terminal board to the
cabinet, a
n
d remove the terminal board from the radar process unit cabinet.
(2) Connect the target tracking unit
's connector to a connector shown in the following photograph.
3-25
