4.13 SLAVE MODE SETTING
(MASTER/SLAVE)
Place the system in the Slave mode when it is to be operated as the sub-display that displays radar echoes by
using radar signals from other radar equipment.
The input value of externally input bearing pulses can be set.
The system can set 2048 pulses or 4096 pulses.
[I] Slave Mode Setting (Master/Slave)
Procedures 1. Open the Serviceman Menu.
2. Perform the following menu open procedure to open the installation
setting menu.
2. Installation Menu
3. Select Slave for the item 2. Master/Slave in the menu.
Master : The system operates as radar equipment while the own antenna is connected.
Slave : The system operates as a sub-display while the signal cable of other radar
equipment is connected.
[II] Setting of Input Bearing Pulse (Input BP Count)
Procedures 1. Open the Serviceman Menu.
2. Perform the following menu open procedure to open the second page of
the installation setting menu.
2. Installation Menu
→ 9. Next
3. Set the number of pulses for the item 1. Input BP Count in the menu.
2048 :2048 pulses per antenna rotation
4096 :4096 pulses per antenna rotation
4-15
To Next Page
