BATTERY & AIRFLOW CHECK: (The lters must be tted)
1. Checking the battery. Insert the male power cable connector into the battery pack. Check the charge level by momentarily pushing the
switch on the battery pack. The 5 LEDs represent 100-80%, 80-60%, 60-40%, 40-20%, 20-0%.
2. Switching on. Hold the unit in the upright position, turn the unit on by pushing and holding the switch on the battery pack. The adjacent
LED charge level indicators will light momentarily. Airow will commence. The drive unit warning buzzer will sound momentarily, release
switch after the unit buzzer is heard. The Heads-Ups Display (HUD) in the visor will ash through its start-up sequence. During use, a
single red indicator will be illuminated.
3. Checking the airow. (Always check the airow level before use using the airow indicator provided). Invert the PowerCap
®
Innity
®
so it
is resting on the helmet and the two lters. Open the peak of the helmet slightly from the drive unit, locate the airow indicator, close the
peak to secure airow indicator.
4. Avoid placing hands or other possible obstructions over the lter inlets. The ball indicator within the airow device should move
fully into the “green zone” this will indicate adequate airow for PowerCap
®
Innity
®
to be used. The ball indicator in the green zone will be
accompanied by a green HUD light. Insufcient ow will be indicated by the ball being all or partly in the “red zone”. If the ow test unit
and/or HUD lights indicate insufcient ow: Check the battery tting and connection and check the charge condition. Check the lter
and pre-lter condition (See Removing & Replacing Filters and Removing & Replacing Pre-Filters sections). In the event that there is still
insufcient airow, do not use the product, but contact JSP Ltd for further advice. The HUD/Audio alert lights should always be the primary
method of assessing ow levels.
