Judo PROFI-PLUS - Extent of Supply and Accessories

JUDO PROFI-PLUS 23
Data Sheet
A = Installation length
B = Unit width
C = Height above pipe centre
D = Height below pipe centre
E = Depth to pipe centre
9.7 Extent of Supply
– Pre-installed filter
– Installation and Operating Instructions
JPF
+
¾" – 1¼":
– Built-in rotary flange JQE ¾", 1" or 1¼"
with bayonet and screw connection
JPF
+
¾" – 1¼"
–2 x Battery for the note electronics
( Typ AAA)
JPF
+
¾" – 1¼":
– Built-in rotary flange JQE 1½" or 2" with
bayonet fixture and screw connection
9.8 Accessories JPF
+
¾" – 2"
JPF
+
¾" – 1¼":
– JUDO JQR expansion quickset Order
no. 8250041 for the series connection of
two devices, e.g. filter and water treat-
ment system.
– JUDO safety block JSB
Order No. 8735260.
For subsequent fil-
ter retrofitting to house water stations.
Contains a pressure reducer, non-return
valve, inlet and outlet pressure manom-
eter
.
JPF
+
1½" – 2":
– JUDO safety block JSB
Order No. 810 5001.
For subsequent fil-
ter retrofitting to house water stations.
Contains a pressure reducer, non-return
valve, inlet and outlet pressure manom-
eter
.
Model A B C D E
JPF
+
¾"
180 130 280 165 165
JPF
+
1"
195 130 280 165 165
JPF
+
1¼"
230 130 280 165 170
JPF
+
1½"
252 154 329 97 205
JPF
+
2"
280 154 329 97 213
All dimensions in [mm]
(siehe Abb. 9:) und Abb. 10:))
