Judo PROFI-PLUS - Spare Parts for JPF+ 1½ - 2

JUDO PROFI-PLUS 27
Spare Parts
List of Spare Parts JPF
+
1½" – 2"
Item
Designation
(Recommended average replacement
interval for wearable parts [*])
Piece(s) Order No.
VE
1)
/Piece
1 Lid of handwheel 1 1607152 7
2 Countersunk screw M5x12 1 1607454 1
3 Washer A 6.4 1 1650142 1
4 Handwheel 1 1607151 23
5
Upper Housing Part JPF
+
1½" – 2"
1 2607107 34
5
Upper Housing Part JPF
+
2"
1 2607108 34
5
Upper Housing Part JPF
+
1½" SMW
2)
1 2010021 34
5
Upper Housing Part JPF
+
2" SMW
2
1 2010022 34
6 Cylinder Screw M6x45 6 1607417 2
7 Flange ring 1 2020102 120
8 Filter hood 1 1607101 371
9 O-ring 15x3.2 **** 1 1607420 2
10 O-ring 28x2.5 **** 1 1200027 3
11 Carrier 1 2020034 25
12 Mouthpiece (Nozzle) **** 2 1607104 10
13 Suction Pipe Gasket **** 1 1607113 3
14 Plate Screw C 2.5x13 1 1607114 1
15 Complete Suction Pipe 1 2607135 122
16 Filter Screen MW 0.10 mm ** 1 2607136 180
17 O-ring 12x3 1 1607110 2
18 Connection Piece 1 1607154 40
19 O-ring 26x3 1 1607111 8
20 O-ring 113.67x5.33 **** 1 1607112 15
21
Filter Bottom Piece JPF
+
1½" – 2"
1 2607102 386
22 Profile flange seal 1 1200230 9
23 Cylinder Screw M8x30 4 1607116 2
24 Washer A 8.4 4 1607125 1
25 Hexagonal nut M8 4 1607117 2
26 Hose Connection 1 1607157 8
Spare part set consisting of Item 9, 10,
12, 13, 14, 16, 20
1 2010225 224
1) VE = Unit of Billing
2) SMW = special mesh size
Replacement interval
** = 2 years
**** = 4 years
Extended warranty period if a maintenance agreement is concluded!
