−27 −
ø26
ø8.5
1
8
19.5
± 0.5
23.5 ± 0.5
17.5 ±0.5
ø26
ø16
9.5 ± 1
32 ± 1
R2
R2
R30
25
(40)
3-26 Dimensions of table
The bed size of this machine is the same as that of JUKI LH model. This machine cannot be set to the table for the
exising lockstitch sewing machines.
Refer to the following dimensions only when JUKI exclusive table is not used since the main dimensions of the
table are described below.
[Reference dimensions of table]
Section F
C1 chamfer
F (reverse side)
C
A
B
D
E
C
C1 chamfer
E
JUKI stand installing position
C1.5 to 2.5 chamfer
(To prevent machine from
being caught when tilting
it)
Section B (1 place)
Section C (2 places)
Section E (2 places)
Section D (2 places)
Section A (3 places)
Rubber cushion installing
drawing for reference
Section C
Section E
To Next Page
