99
3) Press 2 to enter the hook adjusting mode.
4) Zigzag patterns of straight stitch and standard zigzag stitch can be selected in the hook adjusting mode.
Straight stitch
3 : Changeover of straight stitch and standard zigzag stitch can be performed.
4 : Position of stitch base line is set with “+” and “–”.
■Hook adjusting mode setting screen ＜Straight stitch＞
Standard zigzag stitch
5: Changeover of straight stitch and standard zigzag stitch can be performed.
6 : Zigzag width is set with “+” and “–”. (Initial value is set to 8 mm.)
7 : Position of stitch base line is set with “+” and “–”.
3
3
4
4
1) Turn ON the power. When the needle bar is not in the UP position, turn the handwheel to bring the needle
bar to its UP position.
2) Press switch 1 for approximately three seconds to display the information screen.
2
■ Information screen
8-6. Hook adjusting mode
1
When the hook adjusting mode is set, it is possible to adjust the hook by turning the
handwheel.
Cau
tion
