JUKI LU-2810 Series - Connectors that Are Connected in the Head Cover

– 59 –
o
CN58 : 22P connector
Pin No. Part name Remarks
1 — +5V
2 — GND
3 — +5V
4 — GND
5 — +5V
6 — GND
7 — +12V
8 Alternate vertical movement
limit switch
GND
9 — +24V
10 — GND
11 — +24V
12 — GND
13 —
14 —
15 Alternate vertical movement
limit switch (lower side)
16 Alternate vertical movement
limit switch (upper side)
17 —
18 —
19 —
20 —
21 —
22 —
o
CN59 : 26P connector
Pin No. Part name Remarks
1 Solenoid valve +24V
2 Solenoid valve +24V
3 Solenoid valve +24V
4 — +24V
5 Solenoid valve +24V
6 — +24V
7 — +24V
8 — +24V
9 — +24V
10 — +24V
11 Solenoid valve Presser lifting cylinder
12 Solenoid valve Reverse feed cylinder
13 Solenoid valve Alternate vertical movement cylin-
der
14 — —
15 Solenoid valve 2-pitch cylinder
16 — —
17 — —
18 — —
19 — —
20 — —
21 — —
22 — —
23 — —
24 — —
25 — —
26 — —
(2) Connectors that are connected in the head cover
o
CN100 : 14P connector
Pin No. Part name Remarks
1 Thread release solenoid (lower side)
2 Thread trimmer solenoid (right side)
3 Thread release solenoid (upper side)
4 Thread trimmer solenoid (left side)
5 Reverse feed switch GND
6 — —
7 — —
8 Thread release solenoid (lower side) +27V
9 Thread trimmer solenoid (right side) +27V
10 Thread release solenoid (upper side) +27V
11 Thread trimmer solenoid (left side) +27V
12 — —
13 Reverse feed switch
14 — —
o
CN102 : 12P connector
Pin No. Part name Remarks
1 Solenoid valve Presser lifting cylinder
2 Solenoid valve Reverse feed cylinder
3 Solenoid valve Alternate vertical move-
ment cylinder
4 — —
5 Solenoid valve 2-pitch cylinder
6 — —
7 Solenoid valve +24V
8 Solenoid valve +24V
9 Solenoid valve +24V
10 — —
11 Solenoid valve +24V
12 — —
