– 25 –
5) Connect the knee switch to No. 4 and No. 11 of the
sewing machine connector P14.
6) Connect the connector coming from AK device to
CN50-1.
CN50-1
1
7
14
8
Black (No.11) /
White (No.4)
Cords of knee switch
Black line /
White line /
