Output function list
Function
code
Abbrevi-
ation
Function item Remarks
0 noP No function (Standard setting)
1 TrM Thread trimming output Output of thread trimming signal
2 WiP Thread wiper output Output of thread wiper signal
3 TL Thread release output Output of thread release signal
4 FL Presser lifter output Output of presser lifting signal
5 bT Reverse feed stitching output Output of reverse feed stitching signal
6 EbT EBT cancel monitor output State of one time cancel of reverse feed stitching at
end function is output.
7 SEbT Reverse feed stitching at start/
end cancel monitor output
State of cancel of reverse feed stitching at start/end is
output.
8 AUbT Sewing start/end cancellation/
addition monitor output
State of cancel or addition of automatic reverse feed
stitching is output.
9 SSTA
Sewing machine stop state
output
Sewing machine stop state is output.
10 CooL Needle cooler output Output for needle cooler
11 bUZ Buzzer output
It is output when the bobbin counter set value has been
exceeded, an error has occurred or the bobbin thread
remaining amount is detected.
12 LSWo Revolution command output Revolution demanding command state is output.
13 TSWo Tsw command monitor output Thread trimming command status is output.
Input function setting connectors
Output function setting connector
Connector No. Pin No. Display No. Initial value of function setting
CN36 4 i01 noP (No function setting)
CN48 2 i02 SFSW (Safety switch input)
CN50 12 i03 SoFT (Soft-start speed limit input)
CN36 5 i04 bT (Reverse feed stitching switch input)
CN50 11 i05
LinH (Input of prohibition of depress on front part of
pedal)
CN39
7 i06 TSW (Thread trimming switch input)
11 i07 LSSW (Low-speed revolution switch input)
9 i08 HSSW (High-speed revolution switch input)
5 i09 FL (Presser foot lifting switch input)
CN57 1 i10 CUnT (Sewing counter input)
CN42 2 i11 noP (No function setting)
CN54 3 i12 noP (No function setting)
Connector No. Pin No. Display No. Initial value of function setting
CN50
7 o01 bT (Reverse feed stitching output)
8 o02 TrM (Thread trimming output)
9 o03 LSWo (Revolution request input)
