Product description
16
5.3.1 Key description
The device is operated using the key panel. This is used to control all menu
functions and make entries.
Key Function
Press [OK] to start a temperature control application or to
stop a running temperature control application.
Press [OK] to enable a selected function, open a menu
option, or confirm a set value.
Use the arrow keys to select a function or set a value. Short
press for single steps, press and hold for fast counting.
This section describes the electronic interfaces on the device.
For safe operation, the interfaces must be operated according to their
corresponding permissible specifications.
5.3.2 USB-A interface
USB sticks can be connected to the USB-A interface. This unit is capable of
reading data from the USB stick as well as saving data to the USB stick.
Technical data for USB-A interface
Output voltage 5 VDC
Maximum current 500 mA
