Operating controls and functional elements
26
17a
17b
Mains power cable with plug for circulator
Mains power cable with plug cooling machine
18
Built-in mains outlet for connection of circulator
19
Drain screw with drain connection
20
Venting grid, removable
21
22
Pump connectors suction pump pressure pump
23
Selector dial for cooling machine (only F25, F34)
Position "1" for operation with HE circulator.
24
Cooling water OUTLET and INLET.
¾"
