JUMO DICON touch Datasheet

V1.00/EN/00578870
Data Sheet 703571 Page 15/23
JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14
36039 Fulda, Germany
Postal address: 36035 Fulda, Germany
Phone: +49 661 6003-0
Fax: +49 661 6003-607
Email: mail@jumo.net
Internet: www.jumo.net
JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax: +44 1279 635262
Email: sales@jumo.co.uk
Internet: www.jumo.co.uk
JUMO Process Control, Inc.
6733 Myers Road
East Syracuse, NY 13057, USA
Phone: 315-437-5866
1-800-554-5866
Fax: 315-437-5860
Email: info.us@jumo.net
Internet: www.jumousa.com
70357100T10Z002K000
Probes for the operating medium water and oil
Probes for the operating medium water, oil and air
Note: Because of the high response accuracy, the use of thermowells (pockets) is not admissible.
Actual type designation Old type
designation
Probe type Temperature range Nom. length mm P rocess connection
RTD temperature probe Data Sheet 90.2006
90.2006/10-402-1003-1-9-100-104/000 1 x Pt100 -40 ... +400°C 100 G1/2 screw connection
90.2006/10-402-2003-1-9-100-104/000 2 x Pt100 100
902006/54-227-2003-1-15-710-254/000 90.272-F02 2 x Pt100 -170 ... 550°C 65...670 movable
G1/2 compression clamp
902006/54-227-1003-1-15-710-254/000 90.272-F03 1 x Pt100 65...670
902006/10-226-1003-1-9-250-104/000 90.239 1 x Pt100 -170 ... 480°C 250 G1/2 screw connection
902006/10-226-2003-1-9-250-104/000 90-D-239 2 x Pt100 250
Thermocouples Data Sheet 90.1006
901006/54-544-2043-15-710-254/000 90.020-F02 2 x NiCr-Ni, Type „K“ -35 ... 550°C 65...670 movable
G1/2 compression clamp
901006/54-544-1043-15-710-254/000 90.020-F03 1 x NiCr-Ni, Type „K“ 65...670
901006/54-544-2042-15-710-254/000 90.020-F12 2 x FeCuNi, Type „L“ 65...670
901006/54-544-1042-15-710-254/000 90.020-F13 1 x FeCuNi, Type „L“ 65...670
Note: Because of the high response accuracy, only use thermowells (pockets) that are included in the scope of delivery.
Actual type designation Old type
designation
Probe type Temperature range Nom. length mm P rocess connection
RTD temperature probe Data Sheet 90.2006
902006/53-505-2003-1-12-190-815/000 90D239-F03 2 x Pt100 -40 ... +400 °C 190
902006/53-507-2003-1-12-100-815/000 90.239-F02 2 x Pt100
(arranged one
below the other
in protection tube)
-40 ... +480 °C 100
902006/53-507-2003-1-12-160-815/000 90.239-F12 160
902006/53-507-2003-1-12-190-815/000 190
902006/53-507-2003-1-12-220-815/000 90.239-F22 220
902006/53-507-1003-1-12-100-815/000 90.239-F01 1 x Pt100 -40 ... +480 °C 100 weld-in sleeve
902006/53-507-1003-1-12-160-815/000 90.239-F11 160
902006/53-507-1003-1-12-220-815/000 90.239-F21 220
902006/53-505-1003-1-12-190-815/000 90.239-F03 1 x Pt100 -40 ... +400 °C 190
902006/53-505-3003-1-12-100-815/000 90.239-F07 3 x Pt100 -40 ... +400 °C 100
902006/53-505-3003-1-12-160-815/000 90.239-F17 160
902006/53-505-3003-1-12-220-815/000 90.239-F27 220
902006/40-226-1003-1-12-220-815/000 90.280-F30 1 x Pt100 -170 ... +480°C 220 weld-in sleeve
902006/40-226-1003-1-12-160-815/000 90.280-F31 160
902006/40-226-1003-1-12-100-815/000 90.280-F32 100
Thermocouples Data Sheet 90.1006
901006/53-543-1042-12-220-815/000 90.111-F01 1 x Fe-CuNi Type „L“ -35 ... 480°C 220 weld-in sleeve
901006/53-543-2042-12-220-815/000 90.111-F02 2 x Fe-CuNi Type „L“ 220
Note: Because of the high response accuracy, the use of thermowells (pockets) is not admissible.
Actual type designation Old type
designation
Probe type Temperature range Install. length mm P rocess connection
RTD temperature probe Data Sheet 90.2006
90.2006/10-390-1003-1-8-250-104/000 90.210-F95 1 x Pt100 max. 300°C 250
Thermocouples Data Sheet 90.1006
901006/45-551-2043-2-xxxx-11-xxxx 2 x NiCr-Ni, Typ
E
„K“ max. 1
50°C 5
0...2000
