Technical data
Analog inputs
General information
Thermocouples
Standard number Two universal analog inputs
Optional number Two additional universal analog inputs via optional boards
A/D converter Dynamic resolution up to 16-bit (for all input types)
Galvanic isolation See chapter "Galvanic isolation"
Description Standard Measuring range Measuring accuracy
a
a
The accuracy values refer to the maximum measuring range. Smaller measuring ranges lead to reduced linearization accuracy.
Ambient tempera-
ture influence
Fe-CuNi “L” DIN 43 710 -200 to +900 °C  0.25 % 100 ppm/K
Fe-CuNi “J” DIN EN 60584 -200 to +1200 °C  0.25 %  100 ppm/K
Cu-CuNi “U” DIN 43 710 -200 to +600 °C  0.25 %  100 ppm/K
Cu-CuNi “T” DIN EN 60584 -200 to +400 °C  0.25 %  100 ppm/K
NiCr-Ni “K” DIN EN 60584 -200 to +1372 °C  0.25 %
b
b
The accuracy values are first guaranteed from -150°.
 100 ppm/K
NiCr-CuNi “E” DIN EN 60584 -200 to +1000 °C  0.25 %  100 ppm/K
NiCrSi-NiSi “N” DIN EN 60584 -100 to +1300 °C  0.25 %  100 ppm/K
Pt10Rh-Pt “S” DIN EN 60584 -50 to 1768 °C  0.25 %
c
c
The accuracy values are first guaranteed from 0 °C
 100 ppm/K
Pt13Rh-Pt “R” DIN EN 60584
Pt30Rh-Pt6Rh “B” DIN EN 60584 0 to 1820 °C  0.25 %
d
d
The accuracy values are first guaranteed from 300 °C
 100 ppm/K
Pt40Rh-Pt20Rh ASTM E1751M-09 0 to 1888 °C  0.25 %
e
e
The accuracy values are first guaranteed from 600 °C.
 100 ppm/K
Ir40Rh-Ir ASTM E1751M-09 0 to 2110 °C  0.25 %  100 ppm/K
W5Re-W26Re “C” ASTM E230M-11 0 to 2315 °C  0.25 %  100 ppm/K
W3Re-W25Re “D” ASTM E1751M-09 0 to 2315 °C  0.25 %  100 ppm/K
Chromel®-Copel® GOST R 8.585-2001 -200 to +800 °C  0.25 %  100 ppm/K
Chromel®-Alumel® (like NiCr-Ni "K") GOST R 8.585-2001 -200 to +1372 °C  0.25 %  100 ppm/K
Fe-CuNi "L" GOST R 8.585-2001 -200 to +800 °C  0.25 %  100 ppm/K
Smallest measuring span Type L, J, U, T, K, E, N, Chromel®-Alumel®; 100 K
Type S, R, B, D, C, W3Re/W26Re, Chromel®-Cope®l: 500 K
Measuring range start/end Freely programmable within the limits in steps of 0.1 K
Cold junction GOST R Pt100 internal, thermostat constant or external temperature probe
Reference point accuracy (internal)  1K
Reference point temperature (external) 0 to +100 °C adjustable
Sampling rate Controller 1(2): 150 ms in total
Input filter Digital filter, 2nd order, filter constant can be set from 0 to 10.00 s
Special features Can also be programmed in °F
