Analog outputs
Per optional board (OUT3, 5, 7, 9 and OUT11 are possible)
Digital outputs
Standard
Per optional board
Controllers
Screen
1 analog output (configurable)
A/D converter 12 bit resolution
Load resistance R
load
Accuracy Ambient temperature influ-
ence
Voltage DC 0(2) to 10 V
Current DC 0(4) to 20 mA
 500 
 500 
0.25 %
0.25 %
100 ppm/K
±100 ppm/K
Two relay outputs (changeover contact)
Switching capacity AC
Switching capacity DC
Contact life
AC 230V/24V; 3(0,5) A; cosφ=1( 0,6); D300
DC 24V; 3(0,5;  =7ms) A
250,000 operations at nominal load
One relay output (changeover contact)
Switching capacity AC
Switching capacity DC
Contact life
AC 230V/24V; 3(0,5) A; cosφ=1( 0,6); D300
DC 24V; 3(0,5;  =7ms) A
250,000 operations at nominal load
Two relay outputs (N/O contact)
a
Switching capacity AC
Switching capacity DC
Contact life
a
Combining a mains voltage circuit with a protective low-voltage circuit on the "dual normally open contact" option is not admissible.
AC 230V/24V; 3(0,5) A; cosφ=1( 0,6); D300
DC 24V; 3(0,5;  =7ms) A
250,000 operations at nominal load
One solid state relay
Switching capacity
Protection circuitry
1 A at AC 230 V, resistive load
Varistor
Two solid state relay for motor actuators
Switching capacity
Protection circuitry
1 A at AC 230 V,
RC combination
One logic output
(voltage supply for transmitter)
DC 0/22 V, max. 30 mA (short-circuit proof)
Two logic outputs DC 0/12 V max. 20 mA (short-circuit proof, not galvanically isolated)
Two PhotoMOS® relays
b
b
PhotoMOS is a registered trademark of Panasonic Corporation.
DC 45 V, max. 200 mA, (galvanically isolated from each other, not short-circuit proof)
AC 30 V, max. 200 mA, (galvanically isolated from each other, not short-circuit proof)
Controller types Inverse/direct two-state controller, three-state controller, three-state modulating con-
troller, inverse/direct continuous controller, continuous controller with integrated posi-
tion controller
Controller structures P, PD, PI, PID
Sampling rate 150 ms
Parameter blocks Four parameter blocks per controller
Resolution, size 320 × 240 pixels, 3.5 "
Type, number of colors TFT color screen, 256 colors
Brightness setting Adjustable on the device
Device operation Via resistive touchscreen
Screensaver Via waiting period or control signal
Display operating life 50 000 h

JUMO DICON touch Specifications

General

Brand	JUMO
Model	DICON touch
Category	Controller
Language	English
