JUMO DICON touch Datasheet

V1.00/EN/00578870
Data Sheet 703571 Page 7/23
JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14
36039 Fulda, Germany
Postal address: 36035 Fulda, Germany
Phone: +49 661 6003-0
Fax: +49 661 6003-607
Email: mail@jumo.net
Internet: www.jumo.net
JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax: +44 1279 635262
Email: sales@jumo.co.uk
Internet: www.jumo.co.uk
JUMO Process Control, Inc.
6733 Myers Road
East Syracuse, NY 13057, USA
Phone: 315-437-5866
1-800-554-5866
Fax: 315-437-5860
Email: info.us@jumo.net
Internet: www.jumousa.com
70357100T10Z002K000
RTD temperature probe
Description Standard Measuring range Measuring accuracy
a
a
The accuracy values refer to the maximum measuring range. Smaller measuring ranges lead to reduced linearization accuracy.
Ambient
temperature influence
Pt50
Two-wire circuit
Three-wire circuit
DIN EN 60751 -200 to +850 °C  0.05 %  50 ppm/K
Cu50
Two-wire circuit
Three-wire circuit
IEC 60 317 -50 to +200 °C  0.15 %  50 ppm/K
Pt100
Two-wire circuit
Three-wire circuit
DIN EN 60751 -200 to +850 °C  0.05 %  50 ppm/K
Pt500
Two-wire circuit
Three-wire circuit
DIN EN 60751 -200 to +850 °C  0.1 %  50 ppm/K
Pt1000
Two-wire circuit
Three-wire circuit
DIN EN 60751 -200 to +850 °C  0.1 %  50 ppm/K
Ni100
Two-wire circuit
Three-wire circuit
DIN 43760 -60 to +250 °C  0.15 %  50 ppm/K
Ni1000
Two-wire circuit
Three-wire circuit
DIN 43760 -60 to +250 °C  0.1 %  50 ppm/K
KTY11-6
Two-wire circuit
-50to+150°C  1%  50 ppm/K
Pt50
Two-wire circuit
Three-wire circuit
GOST 6651-99 -200 to +850 °C  0.05 %  50 ppm/K
Pt100
Two-wire circuit
Three-wire circuit
GOST 6651-94 -200 to +850 °C  0.05 %  50 ppm/K
Cu50
Two-wire circuit
Three-wire circuit
GOST 6651-94 -50 to +200 °C  0.15 %  50 ppm/K
Cu100
Two-wire circuit
Three-wire circuit
GOST 6651-94 -50 to +200 °C  0.15 %  50 ppm/K
Smallest measuring span 15 K
Measuring current Pt100 approx. 250 A, Pt1000 approx. 100 A
Sen
sor lead resistance Max. 10  per cable for two-wire and three-wire circuits
Lead compensation Not required for a three-wire circuit. For a two-wire circuit, the lead compensation can
be compensated for in the software by correcting the process value.
Measuring range start/end Freely programmable within the limits in steps of 0.1 K
Sampling rate Controller 1(2): 150 ms in total
Input filter Digital filter, 2nd order; filter time constant can be set from 0 to 100 s
Special features Can also be programmed in °F
