4 Supplement
36
Controller
Timers
Electrical data
Requirements for core-end ferrules and cable lugs
Case
Controller type 2-state controller, 3-state controller, continuous controller
Controller structures P/PI/PD/PID
Sampling time 250 ms
A/D converter 16 bit resolution
Accuracy 0.8 % r 10 ppm/K r 250 ms
Voltage supply (switch
mode PSU)
AC 110 to 240 V +10/-15 %, 48 to 63 Hz
AC/DC 20 to 30 V, 48 to 63 Hz
Electrical
safety
as per DIN EN 61010, part 1
overvoltage category III, pollution degree 2
Power consumption max. 14 VA
Electrical connection on the rear via screw terminals; with core-end ferrule of a pipe
shape, ope-n cable lug or pin cable lug
Conductor cross section fine-strand 0.25 to 1.5 mm
2
Tightening torque 0.5 Nm
Electromagnetic
compatibility
as per DIN EN 61326-1
Interference emission Class A - Only for industrial use -
Interference immunity Industrial requirements
Setup interface USB socket, type Mini-B 5-pole
Core-end ferrule pipe shape, without plastic sheath as per DIN 46228 part 1,
with plastic sheath as per DIN 46228 part 4
Cable lug open crimp cable lug, dimensionally adapted to DIN 46237 for
closed crimp cable lugs
Pin cable lug as per DIN 46231
With UL applications use of the cable lugs or ferrules acc. to UL 486A-B (UL listed or
recognized)
Case type plastic case for panel mounting as per IEC 61554 (indoor use)
Dimensions (front) LC100: 48 mm x 48 mm; LC200: 48 mm x 96 mm (portrait format);
LC300: 96 mm x 96 mm
Panel cut-out LC100: 45 mm x 45 mm; LC200: 45 mm x 92 mm;
LC300: 92 mm x 92 mm
Minimum spacing
horizontal / vertical
LC100: 11 mm / 30 mm (65 mm with USB cable);
LC200/LC300: 22 mm / 30 mm (65 mm with USB cable)
Depth behind panel LC100: max. 95 mm; LC200/LC300: max. 80 mm
Ambient / storage
temperature range
-5 to +55 °C / -40 to +70 °C
Ambient conditions rel. humidity < 90% annual average, without condensation
