Jung Smart Visu Server Series User Manual

SV- SERVER / SV-SERVER-INT 137 / 187
Display 2 Byte (Float):
The function "Display 2-Byte" (1) is the KNX function for displaying KNX two-bit values
(floating) in SV-Home. The displayed values are rounded down to the first decimal place.
The function reads the KNX group address entered in the input field "Values (2 Byte)" (2).
As only values can be sent without a unit in the KNX system, the input field "Unit" (3) can
be used to enter an individual unit, which is added to the numerical value in the
visualisation.
In addition, the current status of the function can be polled by defining two initialisation
addresses (4) on starting the system.
Figure 106: Parameters of the "Display 2-byte (Float)" function
The function possesses the following individualisation options within the icon library (5).
KNX function
Selection of the icon library in SV-Control
Operating and display element in SV-Home
Display 2-Byte
Table 55: Display of the "Display 2-Byte Values" function
1
2
3
4
5
