2 Description of controls and indicating instruments
Pos. Controls or
indicating instrument
respectively
EJC
14/16
EJC-Z
14/16
Function
1 Master switch
(Emergency Stop)
tt
The circuit is interrupted, all electric
functions are switched off. The truck is
compulsory braked.
2 Key switch
tt
Switches the control current on and
off. When the key is removed from the
key switch, the truck cannot be opera-
ted by unauthorised persons.
3 Combined instrument
oo
Indicates the remaining capacity of the
battery and the hours of operation that
truck has already performed (see
chapter D).
4 Control shaft
tt
Steering and braking the truck.
5 Button - Shunt driving
tt
If the control shaft is in the upper bra-
king range, the braking function can be
by-passed by pressing
this button. The truck can only be mo-
ved with reduced speed (shunt dri-
ving).
6 Button - wheel arms
lowering
-t
Wheel arms are lowered
with constant speed
7 Button - wheel arms
lifting
-t
Wheel arms are lifted
with constant speed
8 Driving regulator
tt
Controls the driving direction
driving speed.
9 Collision-guard
button
tt
Truck drives away from the operator
and stops.
10 Button -
Lifting the lifting device
tt
Lifting the lifting device.
The lifting speed can be continuously
adjusted with this key (adjustment ran-
ge 8 mm).
11 Button -
Lowering the lifting de-
vice
tt
Lowering the lifting device.
The lowering speed can be conti-
nuously adjusted with this key (adjust-
ment range 8 mm).
12 Button - warning signal
(horn)
tt
Trigger warning signal.
13 Terminal strip
tt
Depositing of freight documents.
14 Control lamp at the
battery charger
o-
Indicates the loading states
(see chapter D).
15 Integrated battery
charger
o-
Used for recharging the battery
16 Document case
oo
Used for depositing documents
t
= Standard equipment
o
= Optional equipment
0401.GB
E 2
2 Description of controls and indicating instruments
Pos. Controls or
indicating instrument
respectively
EJC
14/16
EJC-Z
14/16
Function
1 Master switch
(Emergency Stop)
tt
The circuit is interrupted, all electric
functions are switched off. The truck is
compulsory braked.
2 Key switch
tt
Switches the control current on and
off. When the key is removed from the
key switch, the truck cannot be opera-
ted by unauthorised persons.
3 Combined instrument
oo
Indicates the remaining capacity of the
battery and the hours of operation that
truck has already performed (see
chapter D).
4 Control shaft
tt
Steering and braking the truck.
5 Button - Shunt driving
tt
If the control shaft is in the upper bra-
king range, the braking function can be
by-passed by pressing
this button. The truck can only be mo-
ved with reduced speed (shunt dri-
ving).
6 Button - wheel arms
lowering
-t
Wheel arms are lowered
with constant speed
7 Button - wheel arms
lifting
-t
Wheel arms are lifted
with constant speed
8 Driving regulator
tt
Controls the driving direction
driving speed.
9 Collision-guard
button
tt
Truck drives away from the operator
and stops.
10 Button -
Lifting the lifting device
tt
Lifting the lifting device.
The lifting speed can be continuously
adjusted with this key (adjustment ran-
ge 8 mm).
11 Button -
Lowering the lifting de-
vice
tt
Lowering the lifting device.
The lowering speed can be conti-
nuously adjusted with this key (adjust-
ment range 8 mm).
12 Button - warning signal
(horn)
tt
Trigger warning signal.
13 Terminal strip
tt
Depositing of freight documents.
14 Control lamp at the
battery charger
o-
Indicates the loading states
(see chapter D).
15 Integrated battery
charger
o-
Used for recharging the battery
16 Document case
oo
Used for depositing documents
t
= Standard equipment
o
= Optional equipment
