Flashing sequence/charging curve assignment (ELH 2415/2425/2435)
Flashing
sequence
Charging curves (characteristics)
ELH
2415
ELH
2425
ELH
2435
0 Truck without battery * * *
1
PzS 100 - 300 Ah * * *
PzM to 179 Ah * * *
2
Pulse characteristic
PzS 200 - 400 Ah * * *
PzM 180 - 400Ah * * *
3 PzV 100 - 150 Ah * *
4 PzV 151 - 200 Ah * *
5 PzV 201 - 300 Ah *
6 PzV 301 - 330 Ah *
7
Cold-store characteristic, pulse characteristic PzS 5°C
PzS 200 - 400 Ah * * *
PzM 180 - 400 Ah * * *
8
Not for use
9
10
11
12
Nexsys Bloc +5°C
Nexsys Standard 140 - 177 Ah *
13
Nexsys Bloc +15 °C
Nexsys Standard 140 - 177 Ah *
14
Nexsys Bloc +30 °C
Nexsys Standard 140 - 177 Ah *
15
Not for use16
17
* = Charging curve can be used
NOTICE
u
Set characteristic curve 1 for PzM batteries with capacities less than 180 Ah and
characteristic curve 5 above 180 Ah.
u
Both characteristic curves 1 and 5 can be used for PzS 200-300 Ah wet-cell
batteries, whereby curve 5 results in faster charging.
u
When the battery is connected, this allows you to adjust via the battery charger: If
the switch position is valid, the green LED flashes according to the position set; if
the switch position is invalid, the red LED flashes.
u
If parameter 1388 is incorrectly set, the battery charger will be inhibited and the
battery will not charge. In this case, the charge indicator lights up red continuously.
51
04.19 en-GB
