4.2.3 Charging the battery
Starting to charge with the on-board charger
– ELG mains connection
Mains supply: 230 V / 110 V (+10/-15%)
Mains frequency: 50 Hz / 60 Hz
The mains cable and mains connector (51) of the charger are contained in the
battery compartment with their storage compartment (50) .
Charging the battery
Requirements
– Park the truck securely, see page 70.
– Expose the battery, see page 44.
– Correct charging program set on charger.
Procedure
• Remove any insulating mats from the battery.
• The battery connector must remain plugged.
• Attach the mains connector (51) to a mains socket.
• Pull the Emergency Disconnect switch up.
The flashing LED indicates the charge status or a
fault (for flashing codes see “LED Display” table).
The battery is now charged.
Z
When the mains connector (51) is attached to the mains, all the truck’s electrical
functions are disconnected (electric immobilizer). The truck cannot be operated.
52
04.19 en-GB
