Item Control/display EJD 220 Function
10 Slow-travel button
t
Pressing the slow-travel button
reduces the travel speed and
acceleration. If the tiller is in the
brake zone, pressing this button
overrides the brake function and the
truck can be operated at slow speed.
12 Tiller
t
Used for steering and braking.
13 Charge/discharge indicator
t
Shows the charge/discharge status
of the battery.
CanC
ode
o
Replace
s the key
switch
– Enteri
ng the
appro
priate
code
activa
tes
the
truck
– Travel
-
progr
am
select
ion
– Code
settin
g
– Settin
g of
para
meter
s
17 On-board battery charger
(with safety circuit)
o
For charging the battery when the
mains connector is plugged into a
mains socket.
18 Emergency disconnect
switch
t
Disconnects the battery supply
– All electrical functions are
deactivated and the truck is
braked
55 Support-arm lifting button
t
Lifts the support arms at a constant
speed.
56 Fork lifting button
t
Raises the forks. The lift speed can
be infinitely controlled by the stroke
of the button (8 mm).
62
04.19 en-GB
