6 Aquamatik water replenishment system
6.1 Water replenishment system design
125
126
127
128
129
130
> 3 m
+
-
125 Water container
126 Tap connection with ball cock
127 Flow indicator
128 Shut-off cock
129 Locking coupling
130 Battery lock connector
225
04.19 en-GB
