4.2 Dimensions
Q
c
l
l2
l1
h3
x
h13
Ast
a/2
a/2
b1
Wa
e
b
11
b5
ESE 220 ESE 320
c Load centre distance 600 mm
x Load distance 868 mm
y Wheelbase
1535
1
1541
2
mm
h3 Lift 125 mm
h7 Seat height 1020 mm
h13 Lowered height 90 mm
21
04.19 en-GB
