NOTE: The 4-GB upgrade CompactFlash card and USB to CompactFlash
adapters are the same in both kits. Whereas the PP310 and PP332 use the
same model RTM after you complete the upgrade, the RTMs are jumpered
differently for the two processors. Switching RTMs from a PP310 to a PP332
or vice versa without changing the jumper settings can damage the CPU.
PP833 Upgrade Kit - CTP2000-RAM-RTM-UPG
The PP833 upgrade kit contains:
•
4-GB CTPOS 7.0R1 upgrade CompactFlash card
•
USB to CompactFlash adapter
•
1-GB ECC RAM module (two slots of 4096 MB)
•
Rear transition module (RTM)
•
Jumper (for BIOS reset)
RAM Details
Handle 0x001B, DMI type 17, 34 bytesMemory Device Array Handle: 0x001A
Error Information Handle: 0x001D Total Width: 128 bits Data
Width: 64 bits Size: 4096 MB Form Factor: DIMM Set: None
Locator: ChannelA-DIMM0 Bank Locator: BANK 0 Type: DDR3
Type Detail: Synchronous Speed: Unknown Manufacturer: CCT Memory
Serial Number: No serial number Asset Tag: 0123456789 Part
Number: No part number Rank: Unknown Configured Clock Speed: 1333
MHzHandle 0x001F, DMI type 17, 34 bytesMemory Device Array Handle: 0x001A
Error Information Handle: 0x0021 Total Width: 128 bits Data
Width: 64 bits Size: 4096 MB Form Factor: DIMM Set: None
Locator: ChannelB-DIMM0 Bank Locator: BANK 2 Type: DDR3
Type Detail: Synchronous Speed: Unknown Manufacturer: CCT Memory
Serial Number: No serial number Asset Tag: 0123456789 Part
Number: No part number Rank: Unknown Configured Clock Speed: 1333
MHz
9Copyright © 2015, Juniper Networks, Inc.
Chapter 1: Introduction to CTPOS 7.0 Upgrade Kits
