Table 73: SFP+ Network Port Connector Pinout Informaon (Connued)
Pin Signal Descripon
16 VccT Module transmier 3.3-V supply
17 VeeT Module transmier ground
18 TD+ Transmier noninverted data input
19 TD- Transmier inverted data input
20 VeeT Module transmier ground
Table 74: QSFP+ and QSFP28 Network Port Connector Pinout Informaon
Pin Signal
1 GND
2 TX2n
3 TX2p
4 GND
5 TX4n
6 TX4p
7 GND
8 ModSelL
9 LPMode_Reset
130
