Table 40: JNP10K-PWR-AC2 Power Cable Specifications for 20-A Input (continued)
Graphic
Spare Juniper
Model NumberPlug StandardsCord Set RatingLocale
JNP10K-PWR-AC2 Power Cable Specifications for 30-A Input
The JNP10K-PWR-AC2 HVAC or HVDC power supplies requires a high current cable assembly when set
for 30-A input. One end of the cable has an Anderson APP-400 connector, the other end of the cable is
bare wire. See Figure 45 on page 113 and Table 41 on page 114. These cables are separately orderable and
are not shipped automatically with JNP10K-PWR-AC2 orders. An example of the right-angle cable and
connector is shown in Figure 47 on page 115.
For connection to AC systems, Juniper provides a cable with either a NEMA 30-A connector
(Figure 45 on page 113) or an IEC 330P6W connector (Figure 46 on page 113).
Figure 45: NEMA 30-A Connector
g100610
Figure 46: IEC 330P6W Connector
g100616
