Figure 62: Inserting the AIr Filter into an MX10008 Front Panel
4. Move the air filter frame over the front panel and turn the knob on the air filter frame clockwise back
in place.
NOTE: You must replace the filter every 6 months.
Connecting the MX10000 to Power
IN THIS SECTION
Connecting an MX10000 to Earth Ground | 160
Connecting AC Power to an MX10000 | 163
Connecting DC Power to an MX10000 | 164
158
