Table 10: Fan Tray LEDs on a PTX10000 Router (continued)
DescriptionStateColorName
The left-most SIB behind the right fan tray
is online.
On steadilyGreenSIB 3 status
The beacon feature is enabled. This feature
is enabled using the request chassis
beacon command.
BlinkingGreen
An error has been detected in SIB 3.
Replace the SIB as soon as possible. The
SIB is located behind the right fan tray and
is the left-most SIB in the grouping of 3.
To maintain proper airflow through the
chassis, leave the fan tray installed in the
chassis until you are ready to replace the
SIB.
BlinkingYellow
The SIB is offline.OffNone
The center SIB behind the right fan tray is
online.
On steadilyGreenSIB 4 status
The beacon feature is enabled. This feature
is enabled using the request chassis
beacon command.
BlinkingGreen
An error has been detected in SIB 4.
Replace the SIB as soon as possible. The
SIB is located behind the right fan tray and
is the middle SIB in the grouping of 3. To
maintain proper airflow through the
chassis, leave the fan tray installed in the
chassis until you are ready to replace the
SIB.
BlinkingYellow
The SIB is offline.OffNone
