PTX10008 Components and Configurations
Table 4 on page 35 lists the four hardware configurations for a PTX10008 modular chassis—base (AC and
DC versions) and redundant (AC and DC versions)—and the components included in each configuration.
Table 4: PTX10008 Hardware Configurations
Configuration ComponentsRouter Configuration
•
Chassis, including power bus
•
One Routing and Control Board (RCB)
•
Two fan tray controllers (JNP10008-FAN-CTRL or JNP10008-FTC2)
•
Two fan trays (JNP10008-FAN and JNP10008-FAN2)
•
Three AC power supplies (JNP10K-PWR-AC or JNP10K-PWR-AC2)
•
Three power supply covers
•
Five switch interface boards (SIBs)
•
One SIB cover
•
Eight line card covers
Base AC configuration
PTX10008-BASE
•
Chassis, including power bus
•
One RCB
•
Two fan tray controllers (JNP10008-FAN-CTRL or JNP10008-FTC2)
•
Two fan trays (JNP10008-FAN and JNP10008-FAN2)
•
Three DC power supplies (JNP10K-PWR-DC, JNP10K-PWR-DC2, or
JNP10K-PWR-AC2)
•
Three power supply covers
•
Five SIBs
•
One SIB cover
•
Eight line card covers
Base DC configuration
PTX10008-BASE
•
Chassis, including power bus
•
Two RCBs
•
Two fan tray controllers (JNP10008-FAN-CTRL or JNP10008-FTC2)
•
Two fan trays (JNP10008-FAN and JNP10008-FAN2)
•
Six AC power supplies (JNP10K-PWR-AC or JNP10K-PWR-AC2)
•
Six SIBs
•
Eight line card covers
Redundant AC configuration
PTX10008-PREMIUM
