Table 31: PTX10K-LC1104 Modulation Formats
DistanceModulationSpeed
long haul–2485.49 miles (4000 km)DP-QPSK100 Gbps
regional or metro–1242.74 miles (2000 km)DP-8QAM150 Gbps
metro DCI–621.37 miles (1000 km)DP-16QAM200 Gbps
Compatibility
The Juniper Networks Open Cloud Interconnect solution includes integrated 100-GbE coherent optics on
Juniper Networks QFX Series switches; MX Series 5G Universal Routing Platforms and PTX Series Packet
Transport Routers; and BTI Packet Optical Platforms optimized for DCI. As part of the Open Cloud
Interconnect solution, the PTX10K-LC1104 coherent line card is compatible with many third-party optical
products as well as Juniper Networks optical solutions and offerings. The PTX10K-LC1104 coherent line
card is interoperable with the BTI Series Packet Optical Transport UFM6 in 100-Gbps, and 200-Gbps
modes. It is also compatible with the MX Series MICs and PTX Series PICs in 100-Gbps mode. See
Table 32 on page 102.
Table 32: Juniper Networks Compatible Products in 100 Gbps Mode
Model InformationCardsPlatform
See the Hardware Compatibility Tool, PTX-5-100-WDM.PTX-5-100-WDMPTX Series
See the Hardware Compatibility Tool,
MIC3-100G-DWDM.
MIC3-100G-DWDMMX Series
See the Hardware Compatibility Tool,
QFX10K-12C-DWDM.
QFX10K-12C-DWDMQFX Series
Optical Transmit Specifications
The line card is connected using single-mode fiber (SMF) and LC connectors. See Table 33 on page 102 and
Table 34 on page 103 for the optical transponder specifications.
Table 33: PTX10K-LC1104 Optical Transmit Specifications
ValueSpecification
IEEE 802.3
IEC 60825-1 Class 1
Standards compliance
102
