CAUTION: Before you begin installing the router, ensure that a licensed electrician has
attached an appropriate grounding lug to the grounding cable that you supply. Using a
grounding cable with an incorrectly attached lug can damage the router.
Table 12: Power Input and Output Voltages for JNP10K-PWR-AC2 Power Supplies
Output Power
H/L (High Input 30 A/Low Input
20A)INP1 (Switch 2)INP0 (Switch 1)
5500 WOn (30 A)OnOn
3000 WOff (20 A)OnOn
5000 WOn (30 A)OffOn
5000 WOn (30 A)OnOff
2700 WOff (20 A)OffOn
2700 WOff (20 A)OnOff
The JNP10K-PWR-AC2 requires the enhanced power bus to operate at full power. You can use the standard
bus, but available power is 3000 W for power budget from the power management software. To determine
whether your system has the standard power bus or the enhanced power bus, see “PTX10000 Status
Panel LEDs” on page 41.
JNP10K-PWR-DC Power Supply
The PTX10000 supports three types of DC power supply modules:
•
JNP10K-PWR-DC—A 2500-W, 12-VDC dual power supply.
•
JNP10K-PWR-DC2—A 5500-W, 12-VDC quad input power supply. For details on this power supply,
see “JNP10K-PWR-DC2 Power Supply” on page 68.
•
JNP10K-PWR-AC2—An AC, high-voltage alternating current (HVAC,) or high-voltage direct current
(HVDC) power supply. In high power mode, this power supply provides 12.3 V, 5000 W with a single
feed and 5500 W with dual feeds. For details on this power supply, see “JNP10K-PWR-AC2 Power
Supply” on page 64.
