Table 15: Gigabit Ethernet RJ-45 Connector Pinout
Table 16 lists the cables that you can order from Juniper Networks to connect to a
port on the serial PIM. The device to which you are connecting and the serial
interface type determine which cable you need.
Table 16: Juniper Serial Cables
The E1 and T1 PIMs use an RJ-48 cable, which is not supplied with the PIM.
Table 17 describe the RJ-48 connector pinouts.
Table 17: RJ-48 Connector to RJ-48 Connector (Straight) Pinout
Pin Signal
1
MDI0+
2
MDI0-
3
MDI1+
4
MDI2+
5
MDI2-
6
MDI1-
7
MDI3+
8
MDI3-
Product Number Interface Type Length (in feet) Connector Type
JX-CBL-EIA530-DCE EIA 530 (DCE) 10 feet Female
JX-CBL-EIA530-DTE EIA 530 (DTE) 10 feet Male
JX-CBL-RS232-DCE RS-232 (DCE) 10 feet Female
JX-CBL-RS232-DTE RS-232 (DTE) 10 feet Male
JX-CBL-RS449-DCE RS-449 (DCE) 10 feet Female
JX-CBL-RS449-DTE RS-449 (DTE) 10 feet Male
JX-CBL-V35-DCE V.35 (DCE) 10 feet Female
JX-CBL-V35-DTE V.35 (DTE) 10 feet Male
JX-CBL-X21-DCE X.21 (DCE) 10 feet Female
JX-CBL-X21-DTE X.21 (DTE) 10 feet Male
CAUTION: To maintain agency approvals, use only a properly constructed,
shielded cable.
RJ-48 Pin (on T1/E1 PIM)
(Data Numbering Form)
RJ-48 Pin
(Data Numbering Form)
Signal
1 1 RX, Ring, –
22RX, Tip, +
44TX, Ring, –
5 5 TX, Tip, +
