Table 5: Network Port Connector Pinout Information (continued)
DescriptionSignalPin
Transmit/receive data pair 4TRP4+7
Transmit/receive data pair 4TRP4-8
Related
Documentation
RJ-45 Console Port Connector Pinout Information for WLC100 Wireless LAN Controllers
on page 12
•
• RJ-45 to DB-9 Female Adapter Pinout Information for WLC100 Wireless LAN Controllers
on page 13
• Front Panel of WLC100 Wireless LAN Controllers on page 5
RJ-45 Console Port Connector Pinout Information for WLC100 Wireless LAN Controllers
The RJ-45 console port on WLC100 controllers is an RS-232 serial interface that uses an
RJ-45 connector to connect to a console management device. The default baud rate for
the console port is 9600 baud.
Table 6 on page 12 provides the pinout information for the RJ-45 console connector. An
RJ-45 to DB-9 female adapter is supplied with these controllers.
NOTE: If your laptop or PC does not have a DB-9 male connector pin and you
want to connect your laptop or PC directly to a controller, use a combination
of the RJ-45 to DB-9 female adapter and a USB to DB-9 male adapter. You
must provide the USB to DB-9 male adapter.
Table 6: Console Port Connector Pinout Information for WLC100 Controllers
DescriptionSignalPin
Request to sendRTS Output1
Data terminal readyDTR Output2
Transmit dataTxD Output3
Signal groundSignal Ground4
Signal groundSignal Ground5
Receive dataRxD Input6
Data carrier detectDCD Input7
Clear to sendCTS Input8
Copyright © 2013, Juniper Networks, Inc.12
