EN 55
Front View
1 Shutter Release Button .............. Z pg. 12
Press when you wish to shoot.
2 Flash........................................ Z pg. 20
Lights when shooting under low light or
back light conditions.
3 Flash Sensor ............................. Z pg. 20
Be careful not to cover this area when
using the flash.
4 Infrared Beam Sensor ............... Z pg. 51
Transmits/receives image data via infrared
beam.
5 Lens ........................................ Z pg. 12
Train on the subject.
6 Self-Timer Lamp ....................... Z pg. 19
Blinks when the Self-Timer is activated.
7 PC Jack
Connect to the RS-232C port (Windows
®
)
or to the modem or printer port
(Macintosh
®
) of your computer.
Rear View
8 Power Dial ............................... Z pg. 14
Turn while pressing its Lock Button to
select a shooting mode or the playback
mode.
9 Zoom Button ...................... Z pg. 18, 31
Press to zoom during shooting or to switch
to the next/previous image during play-
back.
0 MENU/BRIGHT/FOCUS
Jog Dial ........................
Z pg. 10, 13, 26
Turn to adjust settings for shooting or
playback, to adjust the brightness of the
LCD monitor or to adjust the focus.
! BATTERY Cover .......................... Z pg. 8
Open to replace the batteries.
@ CLEAR/FOCUS Button .............. Z pg. 26
Press to cancel an effect or to focus on a
subject manually.
# DISPLAY Button ....................... Z pg. 17
Press to make the on-screen display
appear/disappear during playback, or to
cycle through the Standard View mode, the
Standard View with Information Display
mode or the Quick View mode while
shooting.
$ Flash Lamp ............................... Z pg. 20
Lights when the flash is ready.
% FLASH/TRANSFER Button ... Z pg. 20, 50
Press to transfer images by infrared beam
or to charge the flash.
^ VIDEO OUT Jack ..................... Z pg. 30
Connect to a VCR, TV monitor or video
& DC-IN Jack ................................ Z pg. 9
Connect to the optional AC power adapter.
To Next Page
