JVC DX-T5 Service Manual

3-38
Amplifier board (DX-T5)
Block No. [0][7]
R2012 QRL01DJ-471X OMF RESISTOR 470 Ω 1W J
R2014 QRE141J-273Y C RESISTOR 27k Ω 1/4W J
R9201 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9202 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9203 QRE141J-361Y C RESISTOR 360 Ω 1/4W J
R9204 QRE141J-131Y C RESISTOR 130
Ω 1/4W J
R9205 QRE141J-361Y C RESISTOR 360
Ω 1/4W J
R9206 QRE141J-131Y C RESISTOR 130 Ω 1/4W J
R9207 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9208 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9209 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9210 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9218 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9221 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9224 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9227 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9230 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9232 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9300 QRT017J-2R2 MF RESISTOR 2.2 Ω 1W J
R9301 QRE141J-681Y C RESISTOR 680 Ω 1/4W J
R9302 QRZ9006-4R7X F.RESISTOR 4.7
Ω 1/4W J
R9303 QRE141J-271Y C RESISTOR 270
Ω 1/4W J
R9310 QRE141J-470Y C RESISTOR 47 Ω 1/4W J
CN100 QGA7901C1-02 CONNECTOR W-B (1-2)
CN101 QGA7901C1-04 CONNECTOR W-B (1-4)
CN102 QGA7901C1-03 CONNECTOR W-B (1-3)
CN103 QGA3901F1-08 CONNECTOR W-B (1-8)
CN104 QGB2510J1-13 CONNECTOR B-B (1-13)
CN105 QGD2503F1-03 CONNECTOR (1-3)
CN106 QGA3901F1-03 CONNECTOR W-B (1-3)
CN200 QGB2510J1-16 CONNECTOR B-B (1-16)
CN201 QGB2510J1-20 CONNECTOR B-B (1-20)
CN202 QGD2504C1-03Z CONNECTOR (1-3)
CN203 QGB2510K2-13 CONNECTOR B-B (1-13)
CN204 QGB2510K2-13 CONNECTOR B-B (1-13)
CN920 QGF1205C1-08 CONNECTOR FFC/FPC (1-8)
CN930 QGF1036C1-28 CONNECTOR FFC/FPC (1-28)
CN931 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
EP201 E409182-001SM GRAND TERMINAL
H2001 GV40577-001A HEAT SINK
IH920 GV40397-003A IC HOLDER
J920 QNN0624-001 PIN JACK
J921 QNN0557-002 PIN JACK
PP201 QZW0038-001 WIRE CLAMP
PP202 QZW0038-001 WIRE CLAMP
 S1000 QSW0812-001 VOLTAGE SWITCH
Z1001 QNG0003-001Z FUSE CLIP
Z1002 QNG0003-001Z FUSE CLIP
Z1003 QNG0003-001Z FUSE CLIP
Z1004 QNG0003-001Z FUSE CLIP
Z1005 QNG0003-001Z FUSE CLIP
Z1006 QNG0003-001Z FUSE CLIP
Z1007 QNG0003-001Z FUSE CLIP
Z1008 QNG0003-001Z FUSE CLIP
Z1009 QNG0003-001Z FUSE CLIP
Z1010 QNG0003-001Z FUSE CLIP
Z1011 QNG0003-001Z FUSE CLIP
Z1012 QNG0003-001Z FUSE CLIP
Z1013 QNG0003-001Z FUSE CLIP
Z1014 QNG0003-001Z FUSE CLIP
Z1015 QNG0003-001Z FUSE CLIP
Z1016 QNG0003-001Z FUSE CLIP
Z1017 QNG0003-001Z FUSE CLIP
Z1018 QNG0003-001Z FUSE CLIP
Z1019 QNG0003-001Z FUSE CLIP
Z1020 QNG0003-001Z FUSE CLIP
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
 IC302 KIA7809API IC
 IC303 KIA7805API IC
 IC304 KIA7809API IC
 IC305 KIA278R05PI TRANSISTOR
 IC306 KIA278R09PI TRANSISTOR
 IC307 KIA317PI IC
IC308 KIA7805API IC
 IC401 STK412-430 POWER I.C
IC500 PT6305 FL DRIVER
IC510 GP1UM281XKVF IR DETECT UNIT
 Q3901 KTC3203/OY/-T TRANSISTOR
Q3902 KRC102M-T DIGI TRANSISTOR
Q4401 KTC3200/GL/-T TRANSISTOR
Q4402 KTA1023/OY/-T TRANSISTOR
Q4403 KTA1268/GL/-T TRANSISTOR
Q4404 KTC1027/OY/-T TRANSISTOR
Q4601 KTC3199/GL/-T TRANSISTOR
Q4701 KTC3199/GL/-T TRANSISTOR
Q4901 KTC1027/OY/-T TRANSISTOR
Q4902 KTA1023/OY/-T TRANSISTOR
Q4903 KTC3199/GL/-T TRANSISTOR
Q4904 KTA1023/OY/-T TRANSISTOR
Q5004 KRC102M-T DIGI TRANSISTOR
Q5005 KRC102M-T DIGI TRANSISTOR
Q5006 KRC102M-T DIGI TRANSISTOR
Q5007 KRC102M-T DIGI TRANSISTOR
Q5008 KTA1023/OY/-T TRANSISTOR
Q5009 KRC102M-T DIGI TRANSISTOR
Q5010 KRC110M-T TRANSISTOR
Q5011 KTC3199/GL/-T TRANSISTOR
D3701 MTZJ5.6C-T2 Z DIODE
D3811 MTZJ11B-T2 Z DIODE
D3821 MTZJ11B-T2 Z DIODE
D3831 1SS119-041-T2 DIODE
D3832 MTZJ6.2B-T2 Z DIODE
D3841 MTZJ11B-T2 Z DIODE
D3901 MTZJ11B-T2 Z DIODE
D3902 1SS119-041-T2 DIODE
D4401 1SS119-041-T2 DIODE
D4501 MTZJ15B-T2 Z DIODE
D4502 MTZJ15B-T2 Z DIODE
D4503 MTZJ36A-T2 Z DIODE
D4504 MTZJ36A-T2 Z DIODE
D4601 1SS119-041-T2 DIODE
D4701 1SS119-041-T2 DIODE
D4901 1SS119-041-T2 DIODE
D5004 SLI-343URC-W-T LED
D5005 SLI-343URC-W-T LED
D5006 SLI-343URC3F LED
D5007 SLR-343VC-T LED
C3701 QETN1EM-476Z E CAPACITOR 47uF 25V M
C3702 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3811 QETN1EM-476Z E CAPACITOR 47uF 25V M
C3812 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3821 QETN1EM-476Z E CAPACITOR 47uF 25V M
C3822 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3831 QETN1EM-476Z E CAPACITOR 47uF 25V M
C3832 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3841 QETN1EM-476Z E CAPACITOR 47uF 25V M
C3842 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3851 QETN1EM-476Z E CAPACITOR 47uF 25V M
C3852 QETN1CM-107Z E CAPACITOR 100uF 16V M
C4401 QETN1AM-107Z E CAPACITOR 100uF 10V M
C4402 QFZ0212-104Z M CAPACITOR 0.1uF
C4403 QFZ0212-104Z M CAPACITOR 0.1uF
C4404 QETN1HM-105Z E CAPACITOR 1uF 50V M
C4602 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
C4603 QETN1JM-476Z E CAPACITOR 47uF 63V M
C4604 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4605 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4702 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
