JVC DX-T5 Service Manual

3-43
Primary board (DX-T5)
Block No. [0][9]
CN901 QGF1205F1-05 CONNECTOR FFC/FPC (1-5)
FW910 QUM153-21DGZ4-E FLAT WIRE
J700 QNB0261-001 SPK TERMINAL
J800 QNN0732-001 AUX JACK
J880 QNN0284-001 PIN JACK
J901 QNS0252-001 MIC JACK
J902 QNS0252-001 MIC JACK
J910 QNS0170-001 HEADPHONE JACK
K8000 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K8001 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K9100 QQR0621-001Z FERRATE BEADS
RY712 QSK0109-001 RELAY
RY756 QSK0109-001 RELAY
X7700 QAX0711-002Z CRYSTAL 8.000000MHz
 Symbol No. Part No. Part Name Description Local
IC920 BH7868FS-X IC
IC930 GP1FAV30TK0F OPTICAL JACK
Q1000 KTC2026/Y/ TRANSISTOR
Q1001 KTC3203/OY/-T TRANSISTOR
Q2007 KTA1046/Y/ TRANSISTOR
Q2008 KTC3199/GL/-T TRANSISTOR
Q2009 KTC3199/GL/-T TRANSISTOR
Q9300 KRA110M-T TRANSISTOR
Q9301 KRC110M-T TRANSISTOR
Q9303 KTC3199/GL/-T TRANSISTOR
 D1000 1N5402M-20 DIODE
 D1001 1N5402M-20 DIODE
 D1002 1N5402M-20 DIODE
 D1003 1N5402M-20 DIODE
 D1006 6A10E2 SI DIODE
 D1007 6A10E2 SI DIODE
 D1010 6A10E2 SI DIODE
 D1011 6A10E2 SI DIODE
D1012 MTZJ6.2B-T2 Z DIODE
D1013 MTZJ18B-T2 Z DIODE
D1014 MTZJ18B-T2 Z DIODE
D1015 1N4003S-T5 SI DIODE
D1016 1N4003S-T5 SI DIODE
D1017 1N4003S-T5 SI DIODE
 D2001 6A10E2 SI DIODE
 D2002 6A10E2 SI DIODE
 D2003 6A10E2 SI DIODE
 D2004 6A10E2 SI DIODE
D2008 2A02-M DIODE
D2009 MTZJ5.1C-T2 Z DIODE
D2013 1SS133-T2 SI DIODE
D9300 2A02-M DIODE
D9301 MTZJ3.3B-T2 Z DIODE
D9302 MTZJ2.0A-T2 Z DIODE
D9303 MTZJ3.9B-T2 Z DIODE
D9310 MTZJ3.0B-T2 Z DIODE
D9311 1N4003S-T5 SI DIODE
D9312 1N4003S-T5 SI DIODE
D9313 1N4003S-T5 SI DIODE
C1002 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1003 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1004 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C1005 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1010 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1011 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1012 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1013 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K
C1014 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K
C1015 QFKC2EK-103Z MM CAPACITOR 0.01uF 250V K
C1016 QETN2AM-476Z E CAPACITOR 47uF 100V M
C1017 QETN1HM-107Z E CAPACITOR 100uF 50V M
 Symbol No. Part No. Part Name Description Local
C2000 QEZ0706-478 E CAPACITOR 4700uF
C2004 QEZ0706-478 E CAPACITOR 4700uF
C2005 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C2006 QETM1HM-228 E CAPACITOR 2200uF 50V M
C2007 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C2008 QETM1HM-228 E CAPACITOR 2200uF 50V M
C2009 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K
C2010 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C2011 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C2012 QETM1CM-478 E CAPACITOR 4700uF 16V M
C2013 QETM1EM-478 E CAPACITOR 4700uF 25V M
C9200 QETN1AM-477Z E CAPACITOR 470uF 10V M
C9201 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C9204 QETN1HM-105Z E CAPACITOR 1uF 50V M
C9206 QETN1HM-105Z E CAPACITOR 1uF 50V M
C9209 QETN1CM-226Z E CAPACITOR 22uF 16V M
C9211 QETN1HM-105Z E CAPACITOR 1uF 50V M
C9213 QETN1HM-105Z E CAPACITOR 1uF 50V M
C9215 QETN1HM-105Z E CAPACITOR 1uF 50V M
C9216 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C9218 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C9221 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C9224 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C9227 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C9230 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C9232 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C9300 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C9303 QETN1CM-107Z E CAPACITOR 100uF 16V M
 R1000 QRK126J-470X UNF C RESISTOR 47 Ω 1/2W J
R1001 QRE141J-753Y C RESISTOR 75k Ω 1/4W J
R1002 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R1003 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R1005 QRE141J-753Y C RESISTOR 75k Ω 1/4W J
R2000 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R2001 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R2002 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R2003 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R2004 QRE141J-681Y C RESISTOR 680 Ω 1/4W J
R2005 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
R2006 QRE141J-681Y C RESISTOR 680 Ω 1/4W J
R2007 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R2008 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R2009 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R2010 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R2011 QRL01DJ-471X OMF RESISTOR 470 Ω 1W J
R2012 QRL01DJ-471X OMF RESISTOR 470 Ω 1W J
R2014 QRE141J-273Y C RESISTOR 27k Ω 1/4W J
R9201 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9202 QRE141J-391Y C RESISTOR 390
Ω 1/4W J
R9203 QRE141J-361Y C RESISTOR 360 Ω 1/4W J
R9204 QRE141J-131Y C RESISTOR 130
Ω 1/4W J
R9205 QRE141J-361Y C RESISTOR 360
Ω 1/4W J
R9206 QRE141J-131Y C RESISTOR 130 Ω 1/4W J
R9207 QRE141J-391Y C RESISTOR 390
Ω 1/4W J
R9208 QRE141J-391Y C RESISTOR 390
Ω 1/4W J
R9209 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9210 QRE141J-391Y C RESISTOR 390
Ω 1/4W J
R9218 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9221 QRE141J-750Y C RESISTOR 75
Ω 1/4W J
R9224 QRE141J-750Y C RESISTOR 75
Ω 1/4W J
R9227 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9230 QRE141J-750Y C RESISTOR 75
Ω 1/4W J
R9232 QRE141J-750Y C RESISTOR 75
Ω 1/4W J
R9300 QRT017J-2R2 MF RESISTOR 2.2 Ω 1W J
R9301 QRE141J-681Y C RESISTOR 680
Ω 1/4W J
R9302 QRZ9006-4R7X F.RESISTOR 4.7
Ω 1/4W J
R9303 QRE141J-271Y C RESISTOR 270
Ω 1/4W J
R9310 QRE141J-470Y C RESISTOR 47
Ω 1/4W J
CN100 QGA7901C1-02 CONNECTOR W-B (1-2)
CN101 QGA7901C1-04 CONNECTOR W-B (1-4)
CN102 QGA7901C1-03 CONNECTOR W-B (1-3)
CN103 QGA3901F1-08 CONNECTOR W-B (1-8)
CN104 QGB2510J1-13 CONNECTOR B-B (1-13)
CN105 QGD2503F1-03 CONNECTOR (1-3)
CN106 QGA3901F1-03 CONNECTOR W-B (1-3)
CN200 QGB2510J1-12 CONNECTOR B-B (1-12)
 Symbol No. Part No. Part Name Description Local
