Amplifier board (DX-T7)
Block No. [0][4]
R9206 QRE141J-131Y C RESISTOR 130 Ω 1/4W J
R9207 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9208 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9209 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9210 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9218 QRE141J-750Y C RESISTOR 75
Ω 1/4W J
R9221 QRE141J-750Y C RESISTOR 75
Ω 1/4W J
R9224 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9227 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9230 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9232 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9300 QRT017J-2R2 MF RESISTOR 2.2 Ω 1W J
R9301 QRE141J-681Y C RESISTOR 680 Ω 1/4W J
R9302 QRZ9006-4R7X F.RESISTOR 4.7 Ω 1/4W J
R9303 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R9310 QRE141J-470Y C RESISTOR 47 Ω 1/4W J
CN100 QGA7901C1-02 CONNECTOR W-B (1-2)
CN101 QGA7901C1-04 CONNECTOR W-B (1-4)
CN102 QGA7901C1-03 CONNECTOR W-B (1-3)
CN103 QGA3901F1-08 CONNECTOR W-B (1-8)
CN104 QGB2510J1-13 CONNECTOR B-B (1-13)
CN105 QGD2503F1-03 CONNECTOR (1-3)
CN106 QGA3901F1-03 CONNECTOR W-B (1-3)
CN200 QGB2510J1-16 CONNECTOR B-B (1-16)
CN201 QGB2510J1-20 CONNECTOR B-B (1-20)
CN202 QGD2504C1-03Z CONNECTOR (1-3)
CN203 QGB2510K2-15 CONNECTOR B-B (1-15)
CN204 QGB2510K2-13 CONNECTOR B-B (1-13)
CN920 QGF1205C1-08 CONNECTOR FFC/FPC (1-8)
CN930 QGF1036C1-28 CONNECTOR FFC/FPC (1-28)
CN931 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
EP201 E409182-001SM GRAND TERMINAL
H2001 GV40577-001A HEAT SINK
IH920 GV40397-003A IC HOLDER
J920 QNN0624-001 PIN JACK
J921 QNN0557-002 PIN JACK
PP201 QZW0038-001 WIRE CLAMP
PP202 QZW0038-001 WIRE CLAMP
 S1000 QSW0812-001 VOLTAGE SWITCH
Z1001 QNG0003-001Z FUSE CLIP
Z1002 QNG0003-001Z FUSE CLIP
Z1003 QNG0003-001Z FUSE CLIP
Z1004 QNG0003-001Z FUSE CLIP
Z1005 QNG0003-001Z FUSE CLIP
Z1006 QNG0003-001Z FUSE CLIP
Z1007 QNG0003-001Z FUSE CLIP
Z1008 QNG0003-001Z FUSE CLIP
Z1009 QNG0003-001Z FUSE CLIP
Z1010 QNG0003-001Z FUSE CLIP
Z1011 QNG0003-001Z FUSE CLIP
Z1012 QNG0003-001Z FUSE CLIP
Z1013 QNG0003-001Z FUSE CLIP
Z1014 QNG0003-001Z FUSE CLIP
Z1015 QNG0003-001Z FUSE CLIP
Z1016 QNG0003-001Z FUSE CLIP
Z1017 QNG0003-001Z FUSE CLIP
Z1018 QNG0003-001Z FUSE CLIP
Z1019 QNG0003-001Z FUSE CLIP
Z1020 QNG0003-001Z FUSE CLIP
 Symbol No. Part No. Part Name Description Local
IC500 PT6305 FL DRIVER
IC510 GP1UM281XKVF IR DETECT UNIT
 IC601 STK402-240 IC
 IC602 KIA7809API IC
 IC603 KIA7805API IC
 IC604 KIA7809API IC
 IC605 KIA278R05PI TRANSISTOR
 IC606 KIA278R09PI TRANSISTOR
 Symbol No. Part No. Part Name Description Local
 IC607 KIA317PI IC
 IC608 KIA7805API IC
 IC650 STK413-430 IC
Q5004 KRC102M-T DIGI TRANSISTOR
Q5005 KRC102M-T DIGI TRANSISTOR
Q5006 KRC102M-T DIGI TRANSISTOR
Q5007 KRC102M-T DIGI TRANSISTOR
Q5008 KTA1023/OY/-T TRANSISTOR
Q5009 KRC102M-T DIGI TRANSISTOR
Q5010 KRC110M-T TRANSISTOR
Q5011 KTC3199/GL/-T TRANSISTOR
Q6001 KRC102M-T DIGI TRANSISTOR
Q6002 KTA1267/YG/-T TRANSISTOR
Q6211 KTC3199/GL/-T TRANSISTOR
Q6221 KTC3199/GL/-T TRANSISTOR
Q6231 KTC3199/GL/-T TRANSISTOR
Q6351 KTC3203/OY/-T TRANSISTOR
Q6352 KRC102M-T DIGI TRANSISTOR
Q6511 KTC3199/GL/-T TRANSISTOR
Q6521 KTC3199/GL/-T TRANSISTOR
Q6531 KTC3199/GL/-T TRANSISTOR
Q6601 KTC3200/GL/-T TRANSISTOR
Q6602 KTA1023/OY/-T TRANSISTOR
Q6603 KTA1268/GL/-T TRANSISTOR
Q6604 KTC1027/OY/-T TRANSISTOR
Q6701 KTC1027/OY/-T TRANSISTOR
Q6702 KTA1023/OY/-T TRANSISTOR
Q6703 KTC3199/GL/-T TRANSISTOR
Q6704 KTA1023/OY/-T TRANSISTOR
D5004 SLI-343URC-W-T LED
D5005 SLI-343URC-W-T LED
D5006 SELU2E10C-P LED
D5007 SLR-343VC-T LED
D6001 MTZJ9.1B-T2 Z DIODE
D6002 MTZJ9.1B-T2 Z DIODE
D6211 1SS119-041-T2 DIODE
D6221 1SS119-041-T2 DIODE
D6231 1SS119-041-T2 DIODE
D6311 MTZJ11B-T2 Z DIODE
D6321 MTZJ5.6C-T2 Z DIODE
D6331 MTZJ11B-T2 Z DIODE
D6341 1SS119-041-T2 DIODE
D6342 MTZJ6.2B-T2 Z DIODE
D6351 MTZJ11B-T2 Z DIODE
D6352 1SS119-041-T2 DIODE
D6361 MTZJ11B-T2 Z DIODE
D6511 1SS119-041-T2 DIODE
D6521 1SS119-041-T2 DIODE
D6531 1SS119-041-T2 DIODE
D6601 1SS119-041-T2 DIODE
D6701 1SS119-041-T2 DIODE
D6801 MTZJ15B-T2 Z DIODE
D6802 MTZJ15B-T2 Z DIODE
D6803 MTZJ36B-T2 Z DIODE
D6804 MTZJ36B-T2 Z DIODE
C5000 QETN1HM-226Z E CAPACITOR 22uF 50V M
C5001 QETN1HM-226Z E CAPACITOR 22uF 50V M
C5002 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C5003 QEKC1EM-106Z E CAPACITOR 10uF 25V M
C5004 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C5005 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C5006 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C5007 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C6001 QETN1HM-107Z E CAPACITOR 100uF 50V M
C6002 QETN1HM-106Z E CAPACITOR 10uF 50V M
C6003 QETN1HM-106Z E CAPACITOR 10uF 50V M
C6004 QETN1HM-107Z E CAPACITOR 100uF 50V M
C6005 QETN1HM-105Z E CAPACITOR 1uF 50V M
C6111 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C6112 QETN1HM-106Z E CAPACITOR 10uF 50V M
C6113 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C6121 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C6122 QETN1HM-106Z E CAPACITOR 10uF 50V M
C6123 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C6131 QCBB1HK-221Y C CAPACITOR 220pF 50V K
 Symbol No. Part No. Part Name Description Local
