2-20
1
2
3
4
5
A
Cassette housing assembly
S1×3
W1×1
1
Reel disk (SUP) assembly
W1×1
W1×1
P3×1
3
Reel cover assembly
S1×2
S2×1
W1×1
2
Reel disk (TU) assembly
4
Tension arm assembly 5
Release guide assembly
W2×1
6
Idler arm assembly
W1×1
8
Pinch roller arm assembly7 Guide arm assembly
9
Cleaner arm assembly
W1×1 P1×1 P2×1
0
Slant pole arm assembly
S2×3
!
Drum assembly
@
Guide roller (S) assembly
W1×3
#
Rail assembly
2.4 SERVICE NOTE
Use the following chart to manage mechanism parts that are removed for disassembling the mechanism.
Table 2-4-1
