Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
For Connectors
AV
Video output : 1 V (p-p), 75 Ω, analogue
Audio output : 300 mV (rms), 1 kΩ, analogue, stereo
Headphone output
(GR-DVX707 only)
:Stereo
S-VIDEO : Y: 1 V (p-p), 75 Ω, analogue output
C: 0.29 V (p-p), 75 Ω, analogue output
DV
Input/output
(GR-DVX707/507/407 only)
: 4-pin, IEEE 1394 compliant
Output
(GR-DVX400 only)
: 4-pin, IEEE 1394 compliant
USB (GR-DVX707/507 only) :5-pin
EDIT (GR-DVX707/507 only) : ø3.5 mm, 2-pole
JLIP (GR-DVX407/400 only) : ø3.5 mm, 4-pole
PC (GR-DVX407/400 only) : ø2.5 mm, 3-pole
AC Adapter
For General
Power requirement : AC 110 V to 240 Vd, 50 Hz/60 Hz
Output : DC 11.0 V
G, 1.0 A
