Controls
a •Power Zoom Ring [T/W].................... 墌 pg. 20
•Speaker Volume Control.................... 墌 pg. 22
b Recording Start/Stop Button................ 墌 pg. 19
c Power Switch [A, M, P, OFF].......... 墌 pg. 14
d Lock Button ......................................... 墌 pg. 14
e •Snapshot Button [SNAPSHOT] .... 墌 pg. 27, 53
•Information Button [INFO] (GR-DVX707/507
only) .................................................. 墌 pg. 30
f •E-Mail Clip Recording Button [E-MAIL]
(GR-DVX707 only)....................... 墌 pg. 60, 61
•Index Button [INDEX]
(GR-DVX707/507 only) ......... 墌 pg. 30, 59, 71
•Exposure Button [EXPOSURE]
(GR-DVX407/400 only) ..................... 墌 pg. 56
g •Menu Wheel [MENU, +,–] ................. 墌 pg. 38
•LCD Monitor Brightness Control
[BRIGHT, +,–].................................... 墌 pg. 13
h Battery Release Tab [BATT.RELEASE].... 墌 pg. 10
i Cassette Open/Eject Switch
[OPEN/EJECT]...................................... 墌 pg. 16
j •Play/Pause Button [4/9] .................. 墌 pg. 22
•Backlight Compensation Button
[BACKLIGHT] .................................... 墌 pg. 57
k •Fast-Forward Button [5]................ 墌 pg. 22
•Night-Scope Button [NIGHT] ............ 墌 pg. 53
l VIDEO/MEMORY Switch [VIDEO/MEMORY]
(GR-DVX707/507 only) ....................... 墌 pg. 14
m •Rewind Button [3] ........................ 墌 pg. 22
•Focus Adjustment Button
[FOCUS] ............................................ 墌 pg. 55
n •Stop Button [8] ................................. 墌 pg. 22
•Digital Sound Button [D.SOUND]
(GR-DVX707 only)............................. 墌 pg. 59
•D.S.C. Playback Select Button [SELECT]
(GR-DVX707 only)..................... 墌 pg. 28 – 34
o Dioptre Adjustment Control ................ 墌 pg. 12
Connectors
The connectors are located beneath the covers.
P S-Video Output Connector
[S-VIDEO]................................ 墌 pg. 24, 62, 74
Q •Edit Connector [EDIT]
(GR-DVX707/507 only) ..................... 墌 pg. 74
•J Terminal [JLIP (Joint Level Interface
Protocol)] (GR-DVX407/400 only)..... 墌 pg. 74
You can also connect to a JLIP-compatible
camcorder or VCR to control it from the
computer using the optional Software HS-
V16KITE.
R Headphone Connector [ ]
(GR-DVX707 only)............................... 墌 pg. 70
No sound is output from the speaker when
headphones are connected to this connector.
S Audio/Video Output Connector
[AV] ......................................... 墌 pg. 24, 62, 74
T DC Input Connector [DC] ............. 墌 pg. 10, 11
U •USB (Universal Serial Bus) Connector
(GR-DVX707/507 only) ......................墌 pg. 78
•PC Connector
(GR-DVX407/400 only) .....................墌 pg. 78
V Digital Video Connector [DV IN/OUT
(GR-DVX707/507/407) or DV OUT
(GR-DVX400)] (i.Link*) ............墌 pg. 63, 64, 78
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
Indicators
A Power Lamp [POWER]....................墌 pg. 14, 19
B Charge Lamp [CHARGE] ......................墌 pg. 10
C Tally Lamp......................................墌 pg. 19, 48
Other Parts
a LCD Monitor ..................................墌 pg. 13, 20
b Viewfinder............................................墌 pg. 12
c Viewfinder Cleaning Hatch ..................墌 pg. 91
d Speaker ................................................墌 pg. 22
e Cassette Holder Cover..........................墌 pg. 16
f Grip Belt Eyelet ......................................墌 pg. 6
g Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
h Stereo Microphone...............................墌 pg. 70
i Lens
j Flash Sensor (GR-DVX707/507 only)
Be careful not to cover this area, as it contains a
sensor required by the flash.
k Flash (GR-DVX707/507 only)...............墌 pg. 54
l Remote Sensor .....................................墌 pg. 66
m Card Cover [MEMORY CARD]
(GR-DVX707/507 only) ........................墌 pg. 17
n Battery Pack Mount ..............................墌 pg. 10
o Stud Hole
p Tripod Mounting Socket .......................墌 pg. 13
