JVC GY-DV5000 - Technical Specifications

92
13. OTHERS
13-4 Specifications
■ CAMERA SECTION
Image pickup devices: 1/2-inch interline CCD × 3
Color separation optical system:
F1.4 3-color separation prism
Number of effective pixels:
380,000 pixels ((H) 768 × (V) 494)
Color system : NTSC (wide-band R-Y, B-Y
encoder)
Color bars : SMPTE color bar
Sync system : Internal sync (built-in SSG)
Lens mount : Bayonet system (compatible with
1/2” lens)
Optical filter : 3200 K, 5600 K, 5600K + 1/8ND,
5600K + 1/64ND
Sensitivity : F13, 2000 lx
Minimum illumination: 0.2 lux (F1.4, LOLUX Max mode)
Gain : –3, 0, 3, 6, 9, 12, 15, 18 dB, ALC,
LOLUX,
Shutter speed : 1/7.5, 1/15, 1/30, 1/60, 1/100,
1/250, 1/500, 1/1000, 1/2000,
1/4000, 1/10000
V.SCAN speed : 60.1 Hz to 2084.6 Hz
Registration : 0.05% or less (excluding lens
distortion)
Contour correction : Horizontal: dual-edged.
Vertical: 2 H
■ VTR SECTION
Format : DV (SP mode only)
Tape speed : 18.812 mm/sec
(DV SP recording playback)
28.218 mm/sec
(DV CAM playback)
Record/Play time : 276 minutes
(With LA-DV276PRO cassette)
60 minutes
(With M-DV60ME cassette)
F.F/Rewind time : Approx. 3 minutes
(With LA-DV276PRO cassette)
[VIDEO]
Recording format : 8-bit, 13.5 MHz,
4:1:1 component recording
[AUDIO]
Recording format : 16-bit, 48 kHz, 2-channel PCM
audio/12-bit, 32 kHz 4-channel
PCM audio (2 channels for
recording)
Frequency response : 20 Hz to 20 kHz (in 48 kHz mode)
Wow & flutter : Below measurable limit
[Time Code System]
Time code signal : Compliance with SMPTE
standard
■ INPUT/OUTPUT SIGNALS
Video signal output : 1 V (p-p), 75 ohms (BNC)
unbalanced composite output.
YC output : Y 1 V (p-p) 75 ohms unbalance
C 0.286 V (p-p) 75 ohms
unbalance (4-pin)
Lens : 12-pin connector
Audio input : Microphone –60 dBs, 3 kohm
(phantom power
+48V output
supported) (XLR-3)
Line 4 dBs, 10 kohm
balanced (XLR-3)
Audio output : –8 dBs, low impedance,
unbalanced
Earphone output : –60 to –17 dBs, at 8-ohm load
(stereo sound mini-jack)
DC input : 12V DC (11 to 15 V DC) (XLR-4)
Auxiliary power output : 12 V DC, max. 0.1 A (11 to 15 V
DC 4-pin)
DV connector : 4-pin
■ GENERAL
Power consumption : 24 W (with VF-P115B, standard
lens and KA-DV5000) at the time
of recording
Mass : Approx. 5.5 kg (with lens (S14 ×
7.3B12U), viewfinder (VF-P115B),
battery (NP-1B), videocassette
(M-DV30)).
Operating temperatures :0 °C to 40 °C
Operating humidity : 30 % to 80 % RH
Storage temperatures: –20 °C to 60 °C
■ ACCESSORIES
Microphone : × 1 (SCV2987-004)*
Tripod base : × 1 (SCV3021-001)*
Hexagon wrench : × 1 (LW40409-001A)*
Instruction Manual : × 1
* Service parts number
For details, consult your JVC dealer.
Design and specifications are subject to change without
notice.
