JVC HX-Z1

HX-Z1
37
• Pin function
Pin No. Name Function Pin No. Name Function
1 F1R1 Rch GREQ f1 filter setting pin 34 SI Serial data larch receiving pin
2 F1R2 Rch GREQ f1 filter setting pin 35 SCK Serial clook receiving pin
3 F2L1 Lch GREQ f2 filter setting pin 36 A Parallel data receiving pin
4 F2L2 Lch GREQ f2 filter setting pin 37 B Parallel data receiving pin
5 F2R1 Rch GREQ f2 filter setting pin 38 C Parallel data receiving pin
6 F2R2 Rch GREQ f2 filter setting pin 39 BPOUT Output pin for spectrum analyzer
7 F3L1 Lch GREQ f3 filter setting pin 40 BPNF Spectrum analyzer level setting pin
8 FAL2 Lch GREQ f3 filter setting pin 41 INLA Lch input pin A
9 F3R1 Rch GREQ f3 filter setting pin 42 INRA Rch input pin A
10 F3R2 Rch GREQ f3 filter setting pin 43 INLB Lch input pin B
11 F4L1 Lch GREQ f4 filter setting pin 44 INRB Rch input pin B
12 F4L2 Lch GREQ f4 filter setting pin 45 INLC Lch input pin C
13 F4R1 Rch GREQ f4 filter setting pin 46 INRC Rch input pin C
14 F4R2 Rch GREQ f4 filter setting pin 47 INLD Lch input pin D
15 F5L Lch GREQ f5 filter setting pin 48 INRD Rch input pin D
16 F5R Rch GREQ f5 filter setting pin 49 ALCC Time constant of ALC setting pin
17 HPFL1 Lch high-pass filter setting pin 50 ALCR ALC level setting pin
18 HPFL2 Lch high-pass filter setting pin 51 RECL Lch RECOUT output pin
19 HPFL3 Lch high-pass filter setting pin 52 REOR Rch RECOUT output pin
20 HPFR1 Rch high-pass filter setting pin 53 VFC1 Vocal fade filter setting pin
21 HPFR2 Rch high-pass filter setting pin 54 GND Ground pin
22 HPFR3 Dynamic bass filter setting pin 55 VFC2 Vocal fade filter setting pin
23 BASS1 Dynamic bass filter setting pin 56 MIC Input pin for microphone
24 BASS2 Dynamic bass filter setting pin 57 DPLL1 Lch output pin for DPL
25 BASS3 Dynamic bass filter setting pin 58 DPLL2 Lch input pin for DPL
26 BASS4 Dynamic bass filter setting pin 59 DPLR1 Rch output pin for DPL
27 BASS5 Biamp output pin 60 DPLR2 Rch input pin for DPL
28 FILTER VCC/2 pin 61 PS1 Surround setting pin
29 CAP ALC trap frequency setting pin 62 PS2 Surround setting pin
30 VCC Power supply pin 63 F1L1 Lch GREQ f1 filter setting pin
31 OUTR Rch output pin 64 F1L2 Lch GREQ f1 filter setting pin
32 OUTL Lch output pin
33 STEPC Time conatant attachment for
switching shook protection
