KS-LH4R
1-8
Remove the screw C attaching the side bracket
assembly.
Detach the front side of the side bracket assembly
upward and pull out forward to release the joint l and
m in the rear.
1.
2.
Removing the side bracket assembly
(See Fig.10 to 12)
When reassembling, make sure that the
boss n of the main chassis is set in the
notch of the load rack under the side
bracket assembly. Do not reattach the
load rack on the boss n.
CAUTION:
After reattaching the side bracket
assembly, confirm operation.
CAUTION:
Fig.11
Fig.12
Fig.10
C
Side bracket assembly
Side bracket assembly
Joint l
Joint m
Side bracket assembly
Boss n
Load rack
Boss n
Load rack
Joint l
Joint m
