1-2 (No.YA683<Rev.001>)
SPECIFICATION
Design & specifications are subject to change without notice.
Items
Contents
LT-19DA1BJ LT-19DA1BU
Dimensions ( W × H × D ) 38.46 cm × 47.5 cm × 19.0 cm (With stand)]
34.53 cm × 47.5 cm × 9.45 cm (Without stand)]
Mass 4.4 kg (With stand)
4.1 kg (Without stand)
Power Input AC220V - AC240 V, 50 Hz
Power Consumption 68 W
TV RF System Analog CCIR (I) CCIR (B/G, I, D/K, L)
Digital DVB-T
Colour System PAL, SECAM, NTSC 3.58/4.43 [EXT only]
Stereo System NICAM (I) NICAM (B/G, I, D/K, L), A2 (B/G, D/K)
Receiving
Frequency
Analog UHF: 470 MHz - 855.25 MHz VHF: 46.25 MHz - 470MHz
UHF: 470 MHz - 855.25 MHz
CATV: 116MHz - 172MHz / 220MHz - 469MHz
Digital UHF:474 MHz - 858 MHz
Intermediate
Frequency
VIF 38.9MHz 38.9MHz (B/G, I, D/K, L)
SIF 32.9MHz (6.0MHz) 33.4MHz (5.5MHz:B/G)
32.9MHz (6.0MHz:I)
32.4MHz (6.5MHz:D/K)
Colour Sub
Carrier
Frequency
PAL 4.43MHz
SECAM - 4.40625MHz / 4.25MHz
NTSC 3.58MHz / 4.43MHz
Teletext
System
Analog FLOF (Fastext), TOP
Digital MHEG 5 UK profile EBU TEXT
LCD panel 19-inch wide aspect (16 : 10)
Screen Size Diagonal : 48.0 cm (H: 40.8 cm × V: 25.5 cm)
Display Pixels Horizontal : 1440 dots × Vertical : 900 dots
Audio Power Output 1 W + 1 W
Speaker 3.0 cm × 11.0 cm, oval type × 2
Aerial terminal (VHF/UHF) 75 Ω unbalanced, coaxial × 1
EXT-1
(Input)
S-Video Mini-DIN 4 pin × 1
Y: 1 V (p-p), Positive (Negative sync provided), 75 Ω
C: 0.286 V (p-p) (Burst signal), 75 Ω
Video 1V (p-p), Positive (Negative sync provided), 75 Ω, RCA pin jack × 1
Audio 500 mV (rms), High impedance, RCA pin jack × 2
EXT-2 (Input/Output) 21-pin Euro connector (SCART socket ) × 1
EXT-3
(Input)
Component Video
750p / 1125i
625p / 525p / 625i / 525i
RCA pin jack × 3
Y: 1 V (p-p) (Sync signal: ±0.35V(p-p), 3-value sync.), 75Ω / Pb/Pr: ±0.35V(p-p), 75 Ω
Y: 1 V (p-p), Positive (Negative sync.), 75 Ω / Cb/Cr: 0.7V(p-p), 75 Ω
Audio 500 mV(rms) (-4dBs), high impedance, RCA pin jack × 2
EXT-4
(Digital Input)
Video / Audio HDMI 2-row 19pin connector × 1
(Digital-input terminal is not compatible with picture signals of personal computer)
576i(625i),576p(625p),480i(525i),480p(525p),720p(750p),1080i(1125i) signals are available.
EXT-5
(PC Input)
Video D-sub 15 pin × 1
R/G/B : 0.7 V (p-p), 75Ω
HD / VD : 1 V (p-p) to 5 V (p-p), high impedance
< Available signal >
VGA : 640 pixels × 480 pixels (Horizontal : 31.5 kHz / Vertical : 60 Hz)
SVGA : 800 pixels × 600 pixels (Horizontal : 37.9 kHz / Vertical : 60 Hz)
XGA : 1024 pixels × 768 pixels (Horizontal : 48.4 kHz / Vertical : 60 Hz)
WXGA : 1360 pixels × 768 pixels (Horizontal : 47.8 kHz / Vertical : 60 Hz)
Headphone 3.5 mm stereo mini jack × 1
Remote Control Unit RM-C1893B (AA/R6 dry cell battery × 2)
